Probe: OMNI-TERS-NC-Au
OmniTM Tip Enhanced Raman Spectroscopy (TERS) probes designed to acquire topography and enhanced Raman spectral information of a sample simultaneously.
Raman active layer: Au
Quantity: Set of 5 probes.
This probes are compatible with XploRA Nano, LabRAM Nano, OmegaScope and TRIOS systems. They are nanofabricated using highly doped single crystal silicon with unparalleled reproducibility, robustness and sharpness for consistent high resolution imaging capabilities.
Unique features of these probes include:
- Allows all modes of TERS operation – Transmission & Reflection (from top and side accesses)
- Compatible with HORIBA AFM-RAMAN systems.
|
Tip Specifications
|
|
Shape
|
Triangular Pyramid
|
|
Height (µm)
|
10 - 16
|
|
TERS Coating
|
Ti / Au
|
|
Cantilever Specifications
|
|
Material
|
Si
|
|
Shape
|
Rectangular
|
|
Reflex Side Coating
|
Ti / Au
|
|
Parameter
|
Value
|
|
Nominal
|
Minimum
|
Maximum
|
|
Spring Constant (N/m)
|
90
|
30
|
250
|
|
Frequency (kHz)
|
320
|
200
|
510
|
|
Length (µm)
|
150
|
130
|
170
|
|
Width (µm)
|
50
|
43
|
57
|
|
Thickness (µm)
|
5.2
|
4.2
|
6.2
|
Contact us
If you have any further questions, please contact us using our contact us form available here: Contact us.
Notes
The specification range is guaranteed. The values of spring constant and frequency are calculated using mathematical formulation.
